Ignoring for the moment the question of resistance and leakage reactance voltage drops, the condition for a transformer supplying a non-inductive load is shown in phasor form in Fig. Impedances varying considerably from those given may well be encountered in any particular system. Mention has already been made in the introduction of the fact that the transformation between primary and secondary is not perfect.

Book Preview

If the secondary winding is wound in the opposite sense to the primary, additive polarity will result. In other words the percentage voltage drops considered as occurring in either winding remain the same. Load loss is present only when the transformer is loaded, since the magnitude of the no-load current is so small as to produce negligible resistive loss in the windings. Except where that winding is provided with tappings, a case which will be considered shortly. It has also been assumed that the primary and secondary windings of the transformer have been wound in the same sense, so that the induced voltages appear in the same sense.

Account Options

This action might not be possible to undo. It is important to recognise the difference between the two operations described above.

The impression is that the change has been appreciated by readers. Flux density is determined by consideration of the factors identified in the previous section and the choice of core material. We would like to ask you for a moment of your time to fill in a short questionnaire, at the end of your visit.

J & P Transformer Book - 13th Edition

The relationship must basically be a simple one. If a load is connected to the secondary winding which permits the flow of secondary current, then this current creates a demagnetising m. Voltage drops divided between primary and secondary sides.

Single-phase units are also used for the largest generator transformers. In reality, skystar calling software the current which flows is the transformer magnetising current.

It has the special feature that it has a high impedance to normal balanced three-phase voltages, but a low impedance to the flow of single-phase currents. The use of finite-element analysis in the calculation of leakage flux and dielectric stress distributions. The value of l can be used to adjust the reactance since it mainly affects the denominator of Eq.

13th Edition

Firstly, not all of the flux produced by the primary winding links the secondary so the transformer can be said to possess leakage reactance. The transformer also experiences losses. Consultant specializing in power transformers, primarily working for utilities. More will be said about this in a later chapter. Finally, despite the extensive revision involved in the production of the Twelfth and Thirteenth editions, some of the work of the original authors, H.

J & P Transformer Book by Martin Heathcote - Read Online

Voltage drops divided between primary and secondary sides The transference of impedance from one side to another is made as follows. Clearly in this case return yokes must be provided, so that the arrangement becomes as shown in Fig.

Of course, R and X may themselves be expressed as percentage voltage drops, as explained below. Conversely, if high reactance can be tolerated a smaller core can be provided. It is usual therefore to apply various correction factors to l to take account of these practical aspects. This value is always positive and indicates a voltage drop with load. We are always looking for ways to improve customer experience on Elsevier.

Easily read eBooks on smart phones, computers, or any eBook readers, including Kindle. This, of course, holds good for secondary winding leakage reactance and secondary winding resistance in addition to the reactance and resistance of the external load.

The magnetising current is required to take the core through the alternating cycles of flux at a rate determined by system frequency. If you wish to place a tax exempt order please contact us. In fixing this value of nominal flux density some allowance is made for the variations which may occur in practice. It should be noted that the per cent resistance used is that value obtained from the transformer losses, since this takes into account eddy current losses and stray losses within the transformer.

Preceding diagrams have been drawn for single-phase transformers, but they are strictly applicable to polyphase transformers also so long as the conditions for all the phases are shown. In the case of a very large transformer which may be subject to height limitations, usually due to transport restrictions, it may be necessary to reduce the depth of the top and bottom yokes.

Account Options

The most common reason for the addition of a third winding to a three-phase transformer is the provision of a delta-connected tertiary winding. Read on the Scribd mobile app Download the free Scribd mobile app to read anytime, anywhere. It is also possible that a tapped winding may have an axial gap when some of the tappings are not in circuit. The flow of load current in the secondary of the transformer and the m. Looking more closely at Eq.

One possible arrangement is shown in Fig. True, but the industry does change and the Twelfth edition certainly did appear at a time of great change.

This will be discussed further in the later section dealing specifically with autotransformers. This produces a transformer with subtractive polarity, since, if the line terminals of a primary and secondary phase are connected together, the voltages will subtract, as can be seen in Fig.

J & P Transformer Book

International Transformer and Electrical Engineering Consultant. While familiar with the stature of the book when Mr. It is also true that in many branches of the industry the book has become well known and widely respected, and many owners will not consider replacing their trusted old edition.
